Delivery & Lead Time
- Standard Delivery Time: Approximately 8 Weeks
- Around 4 weeks for manufacturing
- Around 4 weeks for shipping and customs clearance
- Free Delivery within New South WalesDelivery is free within NSW, using our own truck specifically designed to transport this size excavator and its accessories safely and efficiently.
Finance & Warranty
- Warranty: 12-Month Parts Warranty
- Finance Options AvailableWe have arranged a chattel mortgage facility through a finance broker, ensuring a smooth and straightforward purchasing process for our customers.
Key Features
✔ High-Performance Engine
42kW of dependable power ensures efficient operation in heavy-duty conditions.
✔ Advanced Hydraulic System
Precision pilot servo controls provide smooth, responsive handling for greater job site efficiency.
✔ Excellent Stability
Heavy-duty 400mm steel tracks enhance traction and balance on uneven terrain.
✔ Operator-Focused Cabin
Fully sealed cabin with air conditioning, LCD display, ergonomic controls, and excellent visibility for all-day comfort.
✔ Attachment Ready
Auxiliary piping allows quick connection to hydraulic attachments such as breakers.
✔ 0.21m³ Standard Bucket
Optimised for efficient digging and material handling.
✔ Dozer Blade Included
Adds versatility for grading and site preparation.
Ideal For
- Construction companies
- Earthmoving contractors
- Landscapers
- Civil projects
- Property developments
Engine Upgrade Available
Upgrade to the trusted Kubota V2607 engine (Euro 5 / EPA compliant) delivering enhanced reliability, fuel efficiency, and consistent performance.
ENGINE
| Item | Specification |
|---|---|
| Emission Standard | Euro V / EPA |
| Make / Model | V2607 |
| Power / Rotation speed | 42kw@2000rpm |
| Type | Diesel with water-cooled, 4-stroke, 4-cylinder |
TRACK SYSTEM
| Item | Specification |
|---|---|
| Maximum Travel Speed | 2.4 / 4.3 km/h |
| Width of Track Shoe | 400mm |
| Number of Track Shoe per Side | 40 pcs |
| Number of Upper Roller per Side | 1 |
| Number of Bottom Roller per Side | 5 |
PERFORMANCE PARAMETER
| Item | Specification |
|---|---|
| Standard Bucket Capacity | 0.21m³ |
| Swing Speed | 11 rpm |
| Maximum Grade Ability | 35° (70%) |
| Maximum Bucket Digging Force | 48KN |
| Maximum Arm Digging Force | 35KN |
| Hydraulic System Pressure | 28Mpa |
| Machine Weight | 5900kg |
| Fuel Tank | 87L |
| Hydraulic Oil Tank | 100L |
MACHINE SIZE
| Item | Specification |
|---|---|
| Overall Dimension (L×W×H) | 5802mm × 1960mm × 2420mm |
| Height of Cabin | 2600mm |
| Track Length on Ground (Axle base) | 1990mm |
| Track Gauge | 1560mm |
| Minimum Ground Clearance | 353mm |
| Swing Radius at Tail | 1520mm |
WORKING RANGE
| Item | Specification |
|---|---|
| Maximum Digging Height | 5928mm |
| Maximum Dumping Height | 4228mm |
| Maximum Digging Depth | 4158mm |
| Maximum Vertical Digging Depth | 3458mm |
| Maximum Digging Radius | 6162mm |
| Minimum Swing Radius | 2389mm |
| Maximum Lifting Height of Blade | 380mm |
| Maximum Cutting Depth of Blade | 455mm |
